Energy-saving high-speed heating far-infrared panel heater PHX series
Heat-tech Far Infrared Panel Heater PHX
Energy-saving high-speed heating far-infrared panel heater PHX series
1. The PHX is a high-speed heating panel heater that reaches 650°C in just 20 seconds. Previously, idling took 30 minutes, but now the idling time can be reduced to zero. 2. The radiation wavelength characteristics are outstanding! The efficiency of radiant heat increases the most when the heater's radiation wavelength matches the absorption wavelength of the heated object. The PHX is a high radiator (emissivity 0.95) that is close to a perfect radiator, making it efficient across all wavelengths, allowing for uniform heating and drying in a short time. It transmits large amounts of heat at the speed of light, enabling miniaturization of the equipment and reduction of heating and drying times. 3. Uniform temperature distribution. The surface has a lattice structure, providing good radiation distribution. Furthermore, the panel heaters made of two or four units are independent, resulting in good temperature distribution within the plane, allowing for uniform heating of the heated object. 4. Clean. The metal heating element is coated with a special ceramic. It is a panel heater composed of a dust-free ceramic heater coated with far-infrared radiation ceramic and a ceramic case. 5. High-precision temperature control. The sensor is embedded in the heater, allowing for high-precision control of the temperature of the heated object.
Inquire About This Product
basic information
ModelVoltageOutputWidthHeightNet Price (Excluding Tax) Direct Sales PriceNet Price (Including Tax) Direct Sales PriceStandard Price (Including Tax) PHX1-50V-690W/KAC50V690W PHX2-100V-1380W/KAC100V1380W PHX3-150V-2070W/KAC150V2070W PHX4-200V-2760W/KAC200V2760W PHX5-200V-2200W/KAC200V2200W PHX6-150V-4140W/KAC150V4140W PHX8-200V-5250W/KAC200V5250W PHX12-200V-8280W/K3-phase AC200V8280W PHX2x2-200V-2760W/KAC200V2760W PHX2x3-150V-4140W/KAC200V4140W PHX2x4-200V-5250W/KAC200V5250W PHX3x4-200V-8280W/K PHX□-□V-□W/KSpecial Order Specification
Price range
Delivery Time
Applications/Examples of results
Small drying oven Touch-up dryer Drying for silk printing Reflow for printed circuit boards Preheating of films Light source for promoting growth and germination in plant factories Curing of epoxy resin Heater unit for drying booths Heating for entrance halls Food warming cabinet Annealing of glass Heating and insulation of car batteries Heating and insulation of wire harnesses Heating and drying of rubber gloves Heating of cover glass for LCDs Multi-stage heating of tires Preheating of prepreg Heating of wool Heating of proteins Promotion of plastic polymerization
Detailed information
-
Annealing of Glass Issues There was no good method for the annealing heater, which was a problem. ⇒ Improvement Points Dried using a far-infrared heater with rapid temperature rise. Since the heater heats up quickly, the operating time has increased. It has also become possible to respond flexibly to unexpected interruption tasks.
-
Heating and Insulation of Car Batteries Issues The battery's performance was inadequate in temperatures close to freezing in winter. ⇒ Improvement Points Insulation was achieved using an instant heating far-infrared heater. The battery was heated quickly, allowing it to perform effectively. Performance tests were conducted successfully.
-
Heating and Insulation of Wire Harnesses Issues The wires were not adapting well in temperatures close to freezing in winter. ⇒ Improvement Points Insulation was achieved using a rapid heating far-infrared heater. The wires adapted well within the engine compartment, allowing for neat wiring.
-
Heating and Drying of Rubber Gloves Issues In temperatures close to freezing in winter, the rubber was not drying, which was problematic. ⇒ Improvement Points Heated with a far-infrared heater that provides instant temperature rise. The startup time is quick, resulting in zero idling time. The heating area is large, allowing for uniform heating and drying of the entire surface. The infrared radiation frequency range is broad, so it can accommodate new materials without needing to replace the heater.
-
Heating of cover glass for LCDs Issues If the glass could bend a little softer, it would improve adhesion. ⇒ Improvement Points Heated with a far-infrared heater that rapidly increases temperature. The rise time is quick, so idle time is reduced to zero, and there is no concern about takt time loss. The heating area is large, allowing for uniform heating and drying of the entire surface. The infrared radiation frequency range is wide, so it can accommodate new materials without needing to replace the heater.
-
Multi-stage heating of tires Issues A responsive heater capable of multi-stage heating was needed. ⇒ Improvement points Heated with the instant temperature rise far-infrared panel heater PHX. Since it can respond to chemical changes, it allows for appropriate curing, improving the quality of the tires.
-
Preheating of prepreg Issues There was no heater that could heat the entire area uniformly. ⇒ Improvement points Heated with a far-infrared panel heater PHX. Since it is a panel heater, it was able to heat the entire area uniformly.
-
Heating of proteins Issues I was looking for a heater that could provide stable heating without contact. ⇒ Points for improvement I heated using the far infrared panel heater PHX. Temperature management can be done in 1°C increments, allowing for confirmation of optimal conditions. It has excellent reproducibility, so quantitative data could be obtained even in additional tests.
-
Promotion of Plastic Polymerization Issues I was looking for a heater that could provide stable heating without contact. ⇒ Improvement Points Heated with the far infrared panel heater PHX. Temperature management can be done in 1°C increments, allowing for the verification of optimal conditions. It has excellent reproducibility, so quantitative data could be obtained even in additional tests.
Line up（12）
| Model number | overview |
|---|---|
| PHX1-50V-690W/K | |
| PHX2-100V-1380W/K | |
| PHX3-150V-2070W/K | |
| PHX4-200V-2760W/K | |
| PHX5-200V-2200W/K | |
| PHX6-150V-4140W/K | |
| PHX8-200V-5250W/K | |
| PHX12-200V-8280W/K | |
| PHX2x2-200V-2760W/K | |
| PHX2x3-150V-4140W/K | |
| PHX2x4-200V-5250W/K | |
| PHX3x4-200V-8280W/K |
